156525 3.7V 16mAh Curved Li-Polymer Battery
Ultra-compact curved lithium-polymer pouch cell with flat tabs for smart-ring integration.
- Model
- 156525
- Chemistry
- Lithium-polymer
- Cathode material
- LiCoO2 (source-listed)
- Nominal voltage
- 3.7 V
PRODUCT BENEFITS
Key Features
Curved pouch form for smart-ring integration
3.7V nominal voltage and 16mAh listed capacity
1.5 × 6.5 × 25 mm format
Flat-tab connection shown
OEM/ODM and drawing-based enquiry supported
PRODUCT DATA
Technical Specifications
Model
156525
Chemistry
Lithium-polymer
Cathode material
LiCoO2 (source-listed)
Nominal voltage
3.7 V
Capacity
16 mAh
Dimensions
1.5 × 6.5 × 25 mm
Weight
Approximately 0.45 g
Terminal form
Flat tabs shown; connector not specified
Operating temperature
-20 to +60 °C
WHERE IT FITS
Product Applications
- Smart rings
- Fitness trackers and smart bands
- Miniature consumer electronics
ENGINEERING SUPPORT
OEM / ODM Customization
- Listed capacity range enquiry: 10–30 mAh
- Listed thickness options: 1.3, 1.5 and 1.8 mm
- Drawing-based and sample-based OEM/ODM enquiry
START A PROJECT
Product Inquiry
Tell KRL about your application, voltage, capacity, dimensions and expected quantity. The existing inquiry form will carry this product reference automatically.
